LP32CM

LP32CM

• Powerful CPU performance
  • 1.basic instruction : 1ns
  • 2.Work memory(POUs) : 1MB
  • 3.Load memory(Data) : 100MB
  • 4.Retain memory(Power-off Holding) : 1MB

• Unlimited Communication
  • 1.EtherCAT master
  • 2.Ethernet/IP master(Scanner)
  • 3.ModbusTCP
  • 4.OPCUA

• Compatibility of Software
  • 1.IEC61131-3 (LD/IL/ST/FBD/SFC)
  • 2.Support PLCopen and PLCopen motion control
  • 3.In-line ST(add ST code when using LD/FBD)
  • 4.CFC (Continuous Function Chart), an inproved free hand FBD

• Rich Build-in Function
  • 1.16DI / 16DO
  • 2.2AI / 1AO
  • 3.PTO(Pulse Train Output) 200KHz x 4
  • 4.HSC(High Speed Counter) 200KHz x 4
  • 5.PWM 200KHz x 4
  • 6.RS485
  • 7.SD card
  • 8.Keep RTC by additional battery or super cap
  • 9.Extend 8 modules

• EtherCAT function
  • 1.up to 4096pts
  • 2.32 Servo Axis
  • 3.Provide Robot function blocks (SCARA/Delta/4~6Axis)
  • 4.Both support G-code and PLCOpen function block
  • 5.DXF import

Specifications
